Scissor Grab

Scissor grab for sheet steel, beams and block-shaped material handling.

Product Description

Scissor Grab — Enhanced Product Description

Technical parameters

ModelMaterial specific gravitySelf weight (Kg)Total lifting capacity (t)Bucket capacity (m3)PulleyWire RopeExternal dimensions（mm）
(t/ m3)DiameterMagnificationdiameterlengthitineraryABCDE
M10.0-1.6-40001.6360010445022214485037404110251040602460
M12.5-1.6-50001.6450012.5550022415511040904480262043802580
M16.0-1.6-64001.65760166.456022616.5581044804890276047202760
M20.0-1.6-80001.6720020863022818.5648049605350296051602940
M25.0-1.6-102001.686802510.263023219.6661051005520326054503170
M32.0-1.6-128001.6115203212.871023621739056906160352060103320
M40.0-1.6-160001.614400401680024023.8827063203520382065603520
M50.0-1.6-200001.618000502090024425.5898067607380412069403790
M63.0-1.6-252001.6226806325.2100024829.31078077408280446079104020
M10.0-2.0-330023400103.345022214485037404110251040602030
M12.5-2.0-41002430012.54.150022415511040904480262043802110
M16.0-2.0-520025600165.256022616.5581044804890276047202240
M20.0-2.0-660026800206.663022818.5648049605350296051602420
M25.0-2.0-830028400258.363023219.6661051005520326054502580
M32.0-2.0-104002112003210.471023621739056906160352060102700
M40.0-2.0-13000214000401380024023.8827063203520382065602860
M50.0-2.0-162002176005016.290024425.5898067607380412069403070
M63.0-2.0-204002222006320.4100024829.31078077408280446079103250

Main Purpose

The Scissor Grab is specially designed for gripping and lifting flat steel plates, metal slabs, beams, block materials, and other plate-shaped loads. Its mechanical scissor action provides a secure and stable grip without requiring hydraulic or electrical power, making it ideal for efficient and safe handling in industrial lifting environments.**

Typical Applications

Scissor grab attachments are commonly used in:

  • Steel structure fabrication workshops for handling plates and beams

  • Metal processing plants requiring fast transfer of slabs or cut sections

  • Logistics and warehouse operations for stacking, loading, and repositioning steel materials

  • Construction and building projects that involve heavy plate movement

  • Manufacturing lines where repeated lifting of flat or rectangular materials is required

Its simple and reliable design makes the scissor grab suitable for overhead cranes, gantry cranes, and other lifting systems used in steel handling environments.**

Key Features

  • Automatic locking mechanism for safe lifting
    The grab automatically tightens as load weight increases, ensuring a secure hold on flat or plate-shaped materials without slippage.

  • No hydraulic or electrical power required
    As a fully mechanical device, this scissor grab attachment operates through a simple lever-and-arm structure, reducing maintenance costs and simplifying installation.

  • Strong clamping force for flat materials
    Ideal for steel plates, slabs, beams, and blocks, providing stable lifting even for heavy or large-size loads.

  • Durable construction for long service life
    Built with high-strength alloy steel and wear-resistant contact surfaces, the grab maintains performance in demanding industrial conditions.

  • Versatile for multiple lifting scenarios
    Compatible with crane hooks and lifting beams, making it suitable for both indoor workshops and outdoor yard handling.

  • Reliable and low-maintenance operation
    With no hydraulic components, the lifting scissor grab offers consistent performance with minimal service needs.**
