Straw Grab — Enhanced Product Description

Straw Grab

The Straw Grab is specifically designed for handling lightweight biomass materials such as agricultural straw, crop residues, and plant waste.
With its large grabbing volume and lightweight structure, it provides an efficient solution for collecting, transferring, and feeding low-density materials in biomass and agricultural applications.

This grab bucket is optimized to maximize throughput while minimizing material loss during handling.

---

Technical Parameters

Straw Grab
Category	Item	Specification
General	Product Name	Straw Grab
	Grab Type	Electro-hydraulic Orange Peel Grab
	Application Material	Straw, biomass, agricultural waste
	Installation	Crane / Hoist / Gantry Crane
Dimensions & Capacity	Grab Size	2400 × 1200 × 900 mm
	Grab Volume (Heaped)	Approx. 4 – 6 m³ (depends on material density)
	Dead Weight	3000 kg
	Handling Density	80 – 150 kg/m³ (typical straw)
Power System	Power Supply	380V / 50Hz / 3 Phase
	Installed Power	11 kW
	Working Pressure	120 bar
	Hydraulic System	Integrated electro-hydraulic power pack
Performance	Opening / Closing Time	≈ 9 s
	Operating Mode	Continuous bulk material handling
	Closing Principle	Optimized for soft, low-density materials
Electrical Protection	Protection Grade	IP55
	Insulation Class	Class F
	Motor Type	Heavy-duty industrial electric motor
Mechanical Design	Pulley Diameter	400 mm
	Jaw Structure	Multi-shell / Orange peel design
	Structural Material	High-strength structural steel
	Surface Treatment	Industrial anti-corrosion coating
Working Conditions	Ambient Temperature	-20 ℃ ~ +50 ℃
	Working Environment	Indoor / Outdoor
	Typical Applications	Biomass power plants, agricultural processing
Optional Configuration	Control Mode	Push button / Radio remote (optional)
	Customization	Grab size, reinforcement, paint color
	Protection Upgrade	IP56 / IP65 (optional)

Main Applications

Straw grabs are mainly used for:

• Handling agricultural straw, hay, and crop residues

• Grabbing and transferring lightweight biomass materials

• Feeding biomass processing and energy systems

Its design ensures stable performance when dealing with soft, loose, and low-density materials that are difficult to handle with conventional grabs.

---

Typical Application Scenarios

Straw grabs are widely applied in:

• Biomass power plants for fuel feeding and material transfer

• Agricultural processing facilities handling straw and plant waste

• Biomass storage yards for loading and unloading operations

• Renewable energy projects using agricultural residues as fuel

They are particularly suitable for continuous operation environments where high-volume, lightweight material handling is required.

---

Key Features & Advantages

• Large-capacity design for lightweight materials
  The grab bucket is designed with a wide opening and optimized tine arrangement, allowing efficient handling of bulky but lightweight biomass.

• Lightweight yet durable structure
  Reduced self-weight improves crane efficiency while maintaining sufficient structural strength for long-term use.

• Optimized for soft and low-density materials
  Specially shaped grab arms minimize material loss when handling straw, hay, and plant waste.

• High handling efficiency
  Larger grabbing volume per cycle increases productivity in biomass and agricultural applications.

• Compatible with various crane systems
  Can be used with overhead cranes, gantry cranes, and material handling cranes in biomass facilities.

---

Why Choose a Straw Grab

Compared with standard grab buckets, a straw grab is specifically engineered for biomass material characteristics, offering higher efficiency, better material retention, and lower operating costs in renewable energy and agricultural processing environments.
