Municipal Waste Grab — Enhanced Product Description

Main Purpose

The main function of the Municipal Waste Grab is to efficiently handle large volumes of soft, loose, and mixed waste. This includes household trash, recyclable fractions, organic waste, packaging waste, and industrial municipal garbage commonly found in waste reception halls and storage pits.

Unlike traditional lifting tools, the Municipal Waste Grab offers superior containment and gripping capability, ensuring secure transfer during lifting cycles and preventing scattered waste or operational interruptions. It significantly improves material handling efficiency in facilities where continuous waste feeding and transportation are required.

---

Technical Parameters

Model	Performance Data（380V 50HZ）			Weight（Kg）		Bucket Capacity(m3)	Number of Bucket Folds	Dimensions（mm）
	Power（KW）	Closing Time（s）	Opening Time（s）	Partial Closure	Fully Closed			A	B	C	D	E	F	a	b
2500	15	10	5	2360	2660	2.5	5	2520	2115	2240	3245	1350	2960	972	350
3200	18.5	12	6	3290	3690	3.2	6	2695	2310	2515	3605	1400	3280	972	350
4000	18.5	11.5	7	3390	3810	4	6	2857	2081	2563	3981	1400	3530	972	350
5000	22	11.5	7	3590	4060	5	6	2961	2216	2724	4166	1400	3760	972	350
6300	30	13.5	7.5	4480	5090	6	6	3433	2586	2975	4633	1545	4240	1012	350
8000	30	13.5	7.5	4680	4750	8	6	3522	2578	3198	4932	1545	4510	1012	350
10000	37	19	11	6400	7310	10	6	3867	2811	3480	5408	1620	4830	1033	350
12000	45	17	14.5	6650	7570	12	6	4320	3540	3960	5360	1620	4895	1033	350

---

Typical Application Scenarios

The Municipal Waste Grab is primarily used in waste-management and environmental processing industries, including:

• Waste-to-energy plants / RDF production lines

• Municipal garbage sorting and transfer stations

• Incineration facilities and landfill processing yards

• Solid waste reception pits and storage silos

• Recycling and environmental sanitation projects

• Automated refuse cranes and waste feeding conveyors

Whether installed on bridge cranes, overhead cranes, or automated crane systems, the Municipal Waste Grab ensures consistent operation and precise waste control in continuous 24/7 industrial environments.

---

Key Features & Advantages

• High Durability and Corrosion Resistance
  Engineered using wear-resistant and anti-corrosion materials, the Municipal Waste Grab withstands acidic liquids, biological decay, and abrasive mixed waste.

• Optimized Jaw Structure for Mixed Waste
  The design enhances penetration, gripping, and retention of irregular garbage materials, reducing loss during transportation.

• Stable and Reliable Heavy-Duty Operation
  Developed for continuous waste processing cycles, this garbage grab supports intensive and long-term workload demands without compromising performance.

• Adaptable to Automated Crane Systems
  Fully compatible with manually controlled and fully automated smart waste-handling systems used in waste-to-energy processing.

• Safety-Driven Engineering
  Designed with anti-drop and anti-swing features to prevent accidental discharge, ensuring safe operation in enclosed or crowded waste pits.

• Low Maintenance & Long Service Life
  Structural reinforcement and high-strength mechanical components reduce downtime and maintenance costs.
